High Quality Smokehouse Oven
moveleft
  • High Quality Smokehouse Oven
  • High Quality Smokehouse Oven
  • High Quality Smokehouse Oven
  • High Quality Smokehouse Oven
moveright

High Quality Smokehouse Oven - |price|picture|parameter|video|manufacturer|for sale|pdf|-GELGOOG

  • MOQ:1 Set /Sets
  • Certification: CE
  • Supply Ability: 100 Sets/ Per Month
  • PAY METHOD: WEST UNION L/C T/T CASH
  • LOADING PORT: Qingdao Port/Shanghai Port, China

Application

The oven is used to cook, dry, bake, smoke and color food, aiming to make food dehydrate and have special flavor.

Main Feature

good efficiency, high quality, stainless steel, favorable price, excellent performance, new design, stable usage, longer life expectancy, evenly heating, environment-friendly, energy saving, meet different needs.
Features
Introduction:
Smokehouse is the best choice to make sausages, seafood, smoked meat, roasted chicken, roasted duck, etc. It is widely used during the meat processing in the food industry. It has been more than ten years from the invention to the development of a wide range of applications. Continuous improvement and integration of domestic and foreign technology through relevant experts, the machine is equipped with cooking, drying, baking, smoking, coloring function and has a very good energy-saving effect. Smoking refers to the process of baking by using timber with the incomplete combustion of volatile substances. The purpose is to make the meat dehydrate, enriching it special flavor. The entire process can improve meat color and have some antiseptic and antioxidant effect, so as to extend the shelf life of meat products. The entire process includes cooking, drying, baking, smoking and coloring. Cooking requires an external steam generator. The steam generator has three heating ways, electric heating, natural gas heating, coal gas heating. The steam generated by the steam pipes into the furnace to achieve the product cooking function. Drying can realized by  electric heating drying and steam heating drying. Baking is by adding fuming material and sugar at appropriate proportions to fume- sending box. Coloring can be adjusted by using different material.
Advantages:
1. Stainless steel material. The material ensures machine quality and life expectancy.
2. Excellent quality. The machine has good workmanship, work stably, and can be very lasting.
3. High efficiency. The heating is very fast and the heating is very even to make the good-quality food.
4. Beautiful and wonderful performance. The high-profile appearance makes you more decent.
5. Large windows made by special explosion-proof membrane. You can have clear observation of the furnace process and can timely exclude sudden accident, being safe and reliable.
6. Independent smoke path. Both sides of the furnace have independent smoke path. The upper part has gas exhaust port and smoke exhaust. Steam convection is set on flank. The purpose is to ensure that the upper and lower furnace temperature is the same and  the effect of smoke from top to bottom is also the same,which avoid inconsistent smoked color.

Technical Data
Model Type Capacity Power High Pressure Low Pressure Furnace Temperature Water Pressure  Trailer Size(mm) Dimension(mm) Weight
GGX-30 Electric 30KG 7.7kw -- <150°C -- 670*680*650 1070*900*1310 230KG
Steam 30KG 3.7kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 670*680*650 1070*900*1310 230KG
GGX-50 Electric 100KG 13kw -- <150°C -- 816*860*1150 1350*1050*1978
1700*1050*1978
700KG
Steam 50KG 4.0kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 700*730*915 1200*1000*1680 330KG
GGX-100 Electric 100KG 13kw -- <150°C -- 816*860*1150 1350*1050*1978
1700*1050*1978
700KG
Steam 100KG 4.2kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 816*860*1150 1350*1050*1978
1700*1050*1978
650KG
GGX-150 Electric 150KG 19.5kw -- <150°C -- 866*880*1250 1740*1100*2160 820KG
Steam 150KG 4.8kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 866*880*1250 1740*1100*2160 820KG
GGX-200 Electric 200KG 24.5kw -- <150°C -- 1000*1000*1380 1800*1200*2600 900KG
Steam 200KG 5.5kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 1000*1000*1380 1800*1200*2600 900KG
GGX-250 Electric 250KG 24.5kw -- <150°C -- 1100*1030*1840 1840*1350*3000 1200KG
Steam 250KG 7.5kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 1100*1030*1840 1840*1350*3000 1200KG
GGX-500 Electric 500KG 61kw -- <150°C -- 1100*1030*1840 1300*3200*3200
1940*2420*3200
2200KG
Steam 500KG 13.5kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 1100*1030*1840 1300*3200*3200
1940*2420*3200
2200KG
GGX-1000 Electric 1000KG 121kw -- <150°C -- 1000*1030*1840 3700*2500*3000
4650*1950*3000
4000KG
Steam 1000KG 24.5kw 0.3-0.6Mpa 0.1-0.2Mpa <120°C 0.2Mpa 1000*1030*1840 3700*2500*3000
4650*1950*3000
4000KG

FAQ
1.Q: What is the voltage/phase for this machine?
  A: We normally make voltage into 220V/50HZ/Single phase or 380V/50HZ/Three Phase. But it can be made according to clients' demand, like 110V/60HZ/Three phase and so on.

2.Q: How long is the guarantee?
  A: We promise guarantee as half of one year for non-human damage factor.

3.Q: How should I do if meet some trouble while using?
  A: Don't worry about that. We are always be pleased to provide using support to clients. We can take a video for showing how to resolve the problem, and write detail resolution to you.
