- Professional Flat-Die Wood Pellet Mill
-
- Brand:GELGOOG
- PAY METHOD:WEST UNION L/C T/T CASH
- Warranty Time:12 Months
- Country Of Origin:China
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
-
Flat-die pellet mill
- Features
- Technical Data
- FAQ
Flat-die pellet mill is used for making fuel pellet,use in school, power plant,hospital and also can make feed pellet with high efficiency, for chicken, cow, duck, sheep and so on. It also can be used to make fertilizer pellet ,multi-functional. The main raw material is widely,such as sawdust,rice husk,cotton stalk,and so on.
Flat-die pellet mill have two parts,one is drive part (include motor, gear case), another part is pelletize part(bearing,mould, roller,knife).
The working principle:Flat-die pellet mill is easy to operate, just put the raw material into the machine from feed port, the mould rotate friction,the roller rotate, by these two power, the raw material was pressed into mould, and be the cylindrical, these pellet will be sent out through the discharge port, in the discharge port, there is knifes, when the pellet go though, the knife will rotate and cut the pellet into small part, according to customer’s demand, the die clearance can be changed to achieved to get different size pellet.
Advantage of Flat-die Pellet Mill
Flat-die pellet mill’s advantage:
1.the drive part install the automatic filtration cycle and lubrication system, to make sure the gear and large bearings can lubrication constantly.
1.the drive part install the automatic filtration cycle and lubrication system, to make sure the gear and large bearings can lubrication constantly.
2.The pellet room have the automatic batch-type oil supply system, lubrication system, to ensure the lubrication between roller and large bearings.
3.Tapered roller can induce the friction which is not necessary.
4.Out flat-die pellet mill set a observation door, you can observe the machine’s working, and check the machine at any time, also it’s convenient to maintain.
5.There is a fan with machine’s gear, can ensure the machine radiating timely.
6.The flat-die pellet mill is easy to operate, and different kinds of type, suitable for home use, farmer, and any other industry.
|
Product name
|
Model
|
Power (kw)
|
Capacity(t/h)
|
|
3-series Flat-die pellet mill
|
GGM3-350
|
37-4
|
0.3-0.5
|
|
GGM3-450
|
55-4
|
0.5-0.8
|
|
|
GGM3-550
|
90-6
|
0.7-1.2
|
|
|
GGM3-800
|
130-160
|
0.7-1.2
|
|
|
GGM4-1200
|
280-320
|
3-5
|
1.Can change the voltage and plugs or not ?
We are manufacturer, mostly products we can change the voltage and plugs. Pls kindly tell me the voltage and plugs that you need before the order.
2.What Methods of Payment Are Acceptable?
Telegraphic Transfer (T/T): we accept 30% T/T deposit before production and 70% T/T Balance before shipment. 100% payment for sample orders.
Western Union: we accept 100% payment via the western union.
3.What is the procedure for making claims for damages or shortages?
All of our products will get fully test before delivery. All shortages must be reported to us within 7 days of receiving the shipment. If the goods were made by carriers then damages need to be reported to them and us. Please make sure that you keep the original shipping box for them to inspect. So please report to us damages made by carriers so that we may file a claim on your behalf.
